Traffic Analysis for Port-Channel2 -- dwdm-switch-1.ams1
| System: | dwdm-switch-1.ams1 in |
| Maintainer: | |
| Description: | Port-Channel2 dwdm-switch-1.ams2 |
| ifType: | IEEE 802.3ad Link Aggregate (161) |
| ifName: | Port-Channel2 |
| Max Speed: | 380.0 Gbits/s |
| Ip: | No Ip (No DNS name) |
The statistics were last updated Saturday, 7 June 2025 at 18:19,
at which time 'dwdm-switch-1.ams1' had been up for 101 days, 14:33:47.
`Daily' Graph (5 Minute Average)
|
Max |
Average |
Current |
| In |
57.6 Gb/s (15.1%) |
53.3 Gb/s (14.0%) |
56.7 Gb/s (14.9%) |
| Out |
184.0 Gb/s (48.4%) |
97.4 Gb/s (25.6%) |
131.9 Gb/s (34.7%) |
`Weekly' Graph (30 Minute Average)
|
Max |
Average |
Current |
| In |
67.0 Gb/s (17.6%) |
55.9 Gb/s (14.7%) |
56.6 Gb/s (14.9%) |
| Out |
258.0 Gb/s (67.9%) |
104.7 Gb/s (27.6%) |
124.9 Gb/s (32.9%) |
`Monthly' Graph (2 Hour Average)
|
Max |
Average |
Current |
| In |
81.8 Gb/s (21.5%) |
33.4 Gb/s (8.8%) |
56.0 Gb/s (14.7%) |
| Out |
322.7 Gb/s (84.9%) |
115.4 Gb/s (30.4%) |
120.5 Gb/s (31.7%) |
`Yearly' Graph (1 Day Average)
|
Max |
Average |
Current |
| In |
75.8 Gb/s (20.0%) |
13.9 Gb/s (3.7%) |
53.8 Gb/s (14.1%) |
| Out |
164.5 Gb/s (43.3%) |
122.6 Gb/s (32.3%) |
89.8 Gb/s (23.6%) |
| GREEN ### |
Incoming Traffic in Bits per Second |
| BLUE ### |
Outgoing Traffic in Bits per Second |
