Traffic Analysis for Port-Channel1 -- dwdm-switch-1.ams2
| System: | dwdm-switch-1.ams2 in |
| Maintainer: | |
| Description: | Port-Channel1 dwdm-switch-1.ams1 |
| ifType: | IEEE 802.3ad Link Aggregate (161) |
| ifName: | Port-Channel1 |
| Max Speed: | 380.0 Gbits/s |
| Ip: | No Ip (No DNS name) |
The statistics were last updated Saturday, 7 June 2025 at 18:29,
at which time 'dwdm-switch-1.ams2' had been up for 473 days, 0:34:52.
`Daily' Graph (5 Minute Average)
|
Max |
Average |
Current |
| In |
184.3 Gb/s (48.5%) |
97.7 Gb/s (25.7%) |
132.7 Gb/s (34.9%) |
| Out |
57.5 Gb/s (15.1%) |
53.4 Gb/s (14.0%) |
56.6 Gb/s (14.9%) |
`Weekly' Graph (30 Minute Average)
|
Max |
Average |
Current |
| In |
257.9 Gb/s (67.9%) |
104.8 Gb/s (27.6%) |
127.4 Gb/s (33.5%) |
| Out |
67.1 Gb/s (17.7%) |
55.9 Gb/s (14.7%) |
56.7 Gb/s (14.9%) |
`Monthly' Graph (2 Hour Average)
|
Max |
Average |
Current |
| In |
322.7 Gb/s (84.9%) |
115.4 Gb/s (30.4%) |
120.5 Gb/s (31.7%) |
| Out |
81.8 Gb/s (21.5%) |
33.4 Gb/s (8.8%) |
56.0 Gb/s (14.7%) |
`Yearly' Graph (1 Day Average)
|
Max |
Average |
Current |
| In |
164.5 Gb/s (43.3%) |
122.6 Gb/s (32.3%) |
89.8 Gb/s (23.6%) |
| Out |
75.8 Gb/s (20.0%) |
13.9 Gb/s (3.7%) |
53.8 Gb/s (14.1%) |
| GREEN ### |
Incoming Traffic in Bits per Second |
| BLUE ### |
Outgoing Traffic in Bits per Second |
